CO2용 전자팽창밸브 개발에 관한 연구 A Study on Development of Electronic Expansion Valve for CO2

안국찬, 김봉환
  • 언어KOR
  • URLhttp://db.koreascholar.com/Article/Detail/291893
PDF 원문보기
한국기계기술학회지 (韓國機械技術學會誌)
제16권 제5호 (2014.10)
pp.1903-1908
한국기계기술학회 (Korean Society of Mechanical Technology)
초록

This study was developed the electronic expansion valve using CO2 refrigerant. The electronic expansion valve consist of bellows, stepping motor, 3-stage reduction gear, poppet and orifice. Structural and flow analysis of electronic expansion valve are carried out using commercial code ANSYS and CFX version 14. Structural analysis was conducted for three type bellows(basic, rib and straight type). Asresults, value of maximum equivalent stress showed that basic type was smaller than rib and straight type.

키워드
Electronic Expansion Valve전자팽창밸브CO2이산화탄소Bellows벨로우즈Orifice오리피스Structural Analysis구조해석Flow Analysis유동해석
