사출성형기 실린더 바디의 최적화 설계에 관한 연구 A Study on the Design for Optimization of Cylinder Body at Injection Molding Machine
pp.943-948
An injection unit is the important part which guide the melted resine into the mold. Once injection molding is performed, there will be a pressure of 33 MPa built up inside of injection cylinder body. It was confirmed that the crack occurs by internal stress on the 9 mm material when the machine is used for long time. Because the cylinder rod has material thickness of 9~12 mm during manufacturing process on the cylinder body, there would be 3 mm thickness differences. In this experiment, IDEAS, a computer aided structure analysis software, is used to present the optimized design condition. Insert rod with inner diameter of 9 mm was set as a normal and vary 3 mm in x, y axis direction. When the internal pressure of 33 MPa occurs at the injection unit, fix the x and y direction and find out the stress acting only in z axis. It was confirmed that the stress of 45~82 N/mm 2 was built up when the left of cylinder body had been set 9 mm by using a structure analysis. Also, it has been verified the thickness of the material on the left need to be greater and equal than 12 mm to prevent a material crack by an internal stress.
