In this paper, the boom of a 30m class refracted insulation with outrigger on aerial elevating work platform is modeled as 3D CAD program of CATIA. The static and dynamic analyses are performed by using ANSYS and ADAMS programs, respectively. The refracted insulation boom uses acetal and the composite boom for insulation. And the composite insulation boom is modeled by using ACP (Ansys Composite Prepost) of ANSYS program. In order to analyze the durability of refracted insulation boom, the static analysis is performed and each analyzed part is stored as =MNF-type flexible body model. The dynamic analysis is performed with ADAMS by using the flexible model. As the result, these analyzes clarify the structural stability and dynamic durability (hot spot) of the refracted insulation boom.

ABSTRACT
 1. 서 론
 2. 해석 방법
  2.1 해석모델
  2.2 ANSYS 정적해석조건
  2.3 ADAMS 동특성해석조건
 3. 해석결과
  3.1 ANSYS 정적해석 결과
  3.2 ADAMS 동특성해석 결과
  3.3 ANSYS 및 ADAMS 해석결과비교
 4. 결 론

• 김진수(Dept. of Mechanical system Engineering, Jeonju University) | Jin-Soo Kim Corresponding Author
• 국호형(Dept. of Mechanical Engineering, Jeonju University) | Ho-Hyeong Guk
