바이크 세차기 노즐의 물 공급 압력과 각도에 따른 세척 효율 분석

장용재, 임동균
  • 언어KOR
  • URLhttp://db.koreascholar.com/Article/Detail/394391
PDF 원문보기
한국기계기술학회지 (韓國機械技術學會誌)
제22권 제2호 (2020.04)
pp.386-392
한국기계기술학회 (Korean Society of Mechanical Technology)
초록

In this paper, internal and external flow analysis of nozzle for a automatic bike washing machine was performed using Ansys Fluent, by varying nozzle injection pressure and angle. The pressure and velocity distributions generated at the nozzle outlet from internal flow analysis were applied for inlet condition of the external flow analysis of the nozzle. As a criterion for the cleaning efficiency, the shear stress condition provided by EHEDG[5] was used and an area of shear stress of 3 Pa or more according to the spray angle and pressure was compared. It is expected that the results of this paper will be applied to the development of automatic contactless bike washing nozzle.

키워드
Computing fluid analysis전산유체해석Multi-phase flow다상 유동Nozzle of car wash세차기 노즐Bike washer바이크 세차기Washing efficiency세척 효율
목차
ABSTRACT
 1. 서 론
 2. 수치모델링
  2.1 지배방정식
  2.2 난류모델
 3. 다상유동기법
  3.1 Volume of Fluid(VOF)
  3.2 Eulerian
  3.3 Lagrangian
 4. 유동 수치 해석
  4.1 해석 모델
  4.2 수치해석
  4.3 수치해석 결과
 5. 결 론
 References
저자
  • 장용재(School of Aeronautical and Mechanical Engineering, Cheong-ju University) | Y. J. JANG
  • 임동균(School of Aeronautical and Mechanical Engineering, Cheong-ju University) | D. K. Im Corresponding Author
