고유진동수 회피를 통한 전투차량 엔진 방열판 파손 개선 Improvement of Heat Screen Failure Through Natural Frequency Avoidance for Battle Tank

김세영, 권유나, 오은빈, 허정남
  • 언어KOR
  • URLhttp://db.koreascholar.com/Article/Detail/437270
PDF 원문보기
한국기계기술학회지 (韓國機械技術學會誌)
제26권 제4호 (2024.08)
pp.789-794
한국기계기술학회 (Korean Society of Mechanical Technology)
초록

In this article, improvement of heat screen failure for battle tank is proposed. The heat screen applied to protect a cam sensor from engine heat was cracked by vibrations generated in the engine. To solve this problem, the configuration of the heat screen was changed to a structure that can avoid engine vibration levels. The improved heat screen has first mode frequency at 4,000 RPM band outside the main operating range of the engine, and heat dissipation is at the same level as conventional heat screen. As a result, the improved heat screen secured reliability by improving vibration effects by approximately 163% while maintaining heat dissipation performance.

키워드
전차엔진배기관방열판고유진동수공진 Battle TankEngineExhaust PipeHeat ScreenNatural FrequencyFrequency Resonance
목차
Abstract
기호설명
1. 서 론
2. 본 론
    2.1 방열판 용접부 파손
    2.3 방열판 파손방지 개선안 도출 및 검증
4. 결 론
References
저자
  • 김세영(Defense Agency for Technology and Quality) | Seyoung Kim Corresponding author
  • 권유나(Defense Agency for Technology and Quality) | Yuna Kwon
  • 오은빈(Defense Agency for Technology and Quality) | Eunbin Oh
  • 허정남(HD Hyndai infracore) | Jungnam Heo
