Dry CVT(Continuously variable transmission) consists of a driving pulley and a driven pulley joined by rubber V-belt. Each pulley consists of a fixed flange and a movable flange. The movable flange of the driving pulley has the centrifugal roller and a ramp plate in the flange. In this study, the formula with respect to relationship between a driving pulley and a driven pulley was derived, based on theoretical investigation about Dry CVT of a common and practical auto-bicycle(125cc). Also, the axial forces on the driving pulley and the driven pulley were analyzed.

Abstract
 1. 서론
 2. 본론
  2.1 무단변속기의 원리
  2.2 구동풀리의 축력 해석
  2.3 종동풀리의 축력 해석
  2.4 SG125 모델의 축력 해석
 3. 결론
 참고문헌

• 이민우(국방과학연구소) | W. M. LEE
