Micro trench structures are applied in gratings, security films, wave guides, and micro fluidics. These micro trench structures have commonly been fabricated by micro electro mechanical system (MEMS) process. However, if the micro trench structures are machined using a diamond tool on large area plate, the resulting process is the most effective man- ufacturing method for products with high quality surfaces and outstanding optical characteristics. A nonferrous metal has been used as a workpiece; recently, and hybrid materials, including polymer materials, have been applied to mold for display fields. Thus, the machining characteristics of polymer materials should be analyzed. In this study, machining characteristics were compared between nonferrous metals and polymer materials using single crystal diamond (SCD) tools; the use of such materials is increasing in machining applications. The experiment was conducted using a square type diamond tool and a shaper machine tool with cutting depths of 2, 4, 6 and 10 µm and a cutting speed of 200 mm/s. The machined surfaces, chip, and cutting force were compared through the experiment.

• 최환진(Devision of Nano-Mechanical Systems, Korea Institute of Machinery and Materials) | Hwan-Jin Choi
• 전은채(Devision of Nano-Mechanical Systems, Korea Institute of Machinery and Materials, University of Science and Technology(UST)) | Eun-chae Jeon
• 최두선(Devision of Nano-Mechanical Systems, Korea Institute of Machinery and Materials, University of Science and Technology(UST)) | Doo-Sun Choi
• 제태진(Devision of Nano-Mechanical Systems, Korea Institute of Machinery and Materials, University of Science and Technology(UST)) | Tae-Jin Je Corresponding Author
• 강명창(National Core Research Center for Hybrid Materials Solution) | Myung-Chang Kang
