In these days, researches about underwater robots have been actively in progress for the purposes of ocean detection and resource exploration. Unlike general underwater robots such as ROV(Remotely Operated Vehicle) and AUV(Autonomous Underwater Vehicle) which have propellers, an articulated underwater robot which is called Crabster has been being developed in KORDI(Korea Ocean Research & Development Institute) with many cooperation organizations since 2010. The robot is expected to be able to walk and swim under the sea with its legs. Among many researching fields of this project, we are focusing on a swimming section. In order to find effective swimming locomotion for the robot, we approached this subject in terms of Biomimetics. As a model of optimized swimming organism in nature, diving beetles were chosen. In the paper, swimming motions of diving beetles were analyzed in viewpoint of robotics for applying them into the swimming motion of the robot. After modeling the kinematics of diving beetle through robotics engineering technique, we obtained swimming patterns of the one of living diving beetles, and then compared them with calculated optimal swimming patterns of a robot leg. As the first trial to compare the locomotion data of legs of the diving beetle with a robot leg, we have sorted two representative swimming patterns such as forwarding and turning. Experimental environment has been set up to get the motion data of diving beetles. The experimental equipment consists of a transparent aquarium and a high speed camera. Various swimming motions of diving beetles were recorded with the camera. After classifying swimming patterns of the diving beetle, we can get angular data of each joint on hind legs by image processing software, Image J. The data were applied to an optimized algorithm for swimming of a robot leg which was designed by robotics engineering technique. Through this procedure, simulated results which show trajectories of a robot leg were compared with trajectories of a leg of a diving beetle in desired directions. As a result, we confirmed considerable similarity in the result of trajectory and joint angles comparison.

• 김희중(Mechatronics Engineering, Chungnam National University) | Kim Hee‐Joong
• 이지홍(Mechatronics Engineering, Chungnam National University) | Lee JI‐HONG Corresponding author
