고도정수처리를 위한 관형 세라믹 정밀여과와 이산화티타늄(TiO2) 광촉매 첨가 PES (polyethersulfone) 구의 혼성공정에서 질소 역세척 주기(FT)와 시간(BT)의 최적운전조건을 막오염에 의한 저항(Rf) 및 투과선속(J), 총여과부피(VT)의 관점에서 고찰하였다. FT가 짧고 BT가 길수록, Rf는 감소하고 J가 증가하여 결국 FT 10분과 BT 30초에서 최대 VT를 얻었다. FT영향 실험 결과 NBF (no back-flushing)에서 막오염이 급격히 진행되어 탁도 및 용존유기물의 처리효율이 가장 높게 나타났다. BT 영향 결과에서는, FT 실험과는 다르게 BT 30초에서 최대 처리효율을 보였다. 결과적으로 FT가 감소하고 BT가 증가할수록 광촉매 첨가 구의 세척이 효율적으로 일어나, 탁도 처리효율은 FT가 짧을수록 95.4%에서 97.5%로, BT가 길수록 95.9%에서 98.5%로 다소 증가하였다. 또한 유기물 처리효율은 FT가 짧을수록 70.8%에서 80.6%로, BT가 길수록 75.1%에서 85.8%로 증가하였다. 본 실험 범위에서 처리효율과 VT가 최대인 최적 질소 역세척 조건은 FT 10분과 BT 30초로 판단된다.
The N2 back-flushing period (FT) and time (BT) were investigated in hybrid process of ceramic microfiltration and PES (polyethersulfone) beads loaded with titanium dioxide (TiO2) photocatalyst for advanced drinking water treatment in viewpoints of membrane fouling resistance (Rf), permeate flux (J), and total permeate volume (VT). As decreasing FT and increasing BT, Rf decreased and J increased, and finally the maximum VT could be acquired at FT 10 min and BT 30 sec. In FT effect experiment, treatment efficiencies of turbidity and dissolved organic matters (DOM) were the highest at no back-flushing (NBF) because of dramatic membrane fouling. As result of BT effect, the treatment efficiencies were the maximum at BT 30 sec, which was different with the FT result. Because the photocatalyst beads could be cleaned effectively as decreasing FT and increasing BT, turbidity treatment efficiency increased a little from 95.4% to 97.5% as decreasing FT, and from 95.9% to 98.5% as increasing BT. Also DOM treatment efficiency increased from 70.8% to 80.6% as decreasing FT, and from 75.1% to 85.8% as increasing BT. The optimal condition, where the treatment efficiencies and VT were the maximum, should be FT 10 min and BT 30 sec in our experimental range.
