지지체인 Polyacrylonitrile (PAN) 중공사에 Poly (vinyl alcohol) (PVA)과 가교제인 Glutaraldehyde (GA)를 코팅하 여 막을 제조하였으며, 특성평가를 위해 물/Isopropyl alcohol (IPA) 혼합액에 대한 투과증발 실험을 수행하였다. 코팅용액의 조성변화와 반응온도의 조건변화에 따른 투과도 및 선택도를 측정하였고, 공급액의 조성은 85 wt% IPA 수용액을 사용하였으며, 온도는 30, 50, 70, 90℃로 변화시켰다. 투과도는 PVA 3.5 wt%, 공급액 온도가 90℃일 때 1,870 g/m 2 ⋅hr, 선택도는 PVA 7 wt% 공급액 온도가 30℃일 때 804로 가장 높은 값을 얻을 수 있었다.
Poly (vinyl alcohol) (PVA) solution containing the glutaraldehyde (GA) as a crosslinking agent was coated onto the polyacrylonitrile (PAN) hollow fiber membrane as the supporter. Pervaporation experiments were carried out to characterize the prepared PVA/PAN composite membrane for water-isopropyl alcohol mixture. The flux and separation factor were measured at 30, 50, 90℃ for the feed mixture of aqueous 85 wt% IPA solution with varying the reaction temperature and composition of coating solutions. Typically the flux showed 1,870 g/m 2 ⋅hr at 90℃ feed mixture and the coating concentration of 3.5 wt% and the highest separation factor of 804 was obtained at 30℃ feed mixture and the coating concentration of 7 wt% as well.
