pp.55-65
Spotted cordierite occurs as the result of intrusion of Wolaksan Granite of Cretaceous age in the northern part of the Ogcheon Metamorphic Belt, forming a contact metamorphic zoning in accordance with the distance from the granite body: a cordierite-muscovite-biotite-quartz assemblage and the higher-temperature cordierite-biotite-quartz-(cummingtonite). These quartz-ubiquitous mineral assemblages identified in the cordierite spot seem to reflect Al-deficient condition of the protolith. TEM observations of textural relations between the cordierite and mica within the cordierite spot clearly reflect that cordierite was formed at the expense of micaceous matrix. A structure refinement of the poikiloblastic cordierite was performed by the Rietveld refinement method. Unit cell of the cordierite was determined to be as follows : lower-temperature type: a=17.1480(9)a, b=9.7743(6)a, c=9.3184(5)a, V=1561.9(4)a3, higher-temperature type: a=17.136(2)a, b=9.751(1)a, c=9.322(1)a, V=1557.7(4)a3. They show a remarkable difference in the unit cell dimension. The refinement results indicate that structural sites of lower-temperature cordierite are wholly occupied by appropriating ions. Compared to this, tetrahedral sites of the higher-temperature type exhibit an order/disorder ranging about 5-8% as the result of substitution between Si4+ and Al3+, except for T26 site occupied wholly by Al3+. These structural differences seem to be related to the formation temperatures of both cordierite types.
