재활용된 암버력-토사의 회복탄성계수 예측모델이 개발되었다. 반복삼축시험을 통한 회복탄성계수의 전통적 평가방법은 큰 입경을 가진 자갈에는 실현 불가능하다. 미세한 차이가 있는 비선형 전단탄성계수를 이용하여 회복탄성계수를 산출하는 대체기법을 제안하였다. 현장에서 측정한 최대전단탄성계수와 대형공진주 시험으로 구한 감소곡선을 이용하여 회복탄성계수 예측모델을 개발하였다. 이 예측모델을 김천의 고속도로공사현장에서 재활용한 암버력-토사에 적용하여 모델인자 AE, nE, εr, α를 각각 9618, 0.47, 0.0135, 0.8로 제안하였다.

A prediction model of resilient modulus(ER) was developed for recycled crushed-rock-soil mixtures. The evaluation of ER, using the "orthodox" repeated loading tri-axial test, is not feasible for such a large-size gravelly material. An alternative method was proposed hereby using the subtle different modulus called nonlinear dynamic modulus. The prediction model was developed by utilizing in-situ measured shear modulus(Gmax) and its reduction curves of modeled materials using the large free-free resonant column test. A pilot evaluation of the model parameters was carried out for recycled crushed-rock-soil-mixture at a highway construction site near Gimcheon, Korea. The values of the model parameters(AE, nE, εr and α) were proposed as 9618, 0.47, 0.0135, and 0.8, respectively.

• 박인범 | Park, In-Beom
• 목영진 | Mok, Young-Jin
