멸치초망용 챗대의 유압 권양장치를 개발하기 위하여 모형 챗대와 그물을 실물의 1/5크기로 제작하여 챗대를 권양할 때의 장력을 측정하고, 이를 토대로 권양기 3종을 설계 제작하여 그 성능을 시험한 결과를 요약하면 다음과 같다. 1. 챗대를 건양하는데 가장 큰 장력이 작용할 때는 챗대 끝이 수면 하 4m에 있을 때이었고, 이 때 챗대줄에 작용하는 장력은 187.5kgf이었다. 2. 멸치초망 어업에 적합한 권양기의 조건은 어탐중 챗대가 움직이지 않아야 하며, 그 방법으로 감속기나 전자브레이크를 장치하는 것보다 시간 경과에 따른 누수량이 적은 것을 사용하는 것이 바람직하였다. 3. 시험에 사용된 권양기 중 최적의 권양기에 있어서 압력차 δP를 130kgf/ cm2으로 고정하였을 때, 권양기에 감겨지는 챗대줄의 권양속도는 2m/sec로서 재래식 방법보다 0.48m/sec 빠르게 나타났으며, 양망당 약 1.6톤의 멸치를 어획할 수 있다. 4. 권양기 2대를 설치함으로써 조업인원 2명을 절감할 수 있었다.

Anchovy, EngrauEis japonica scoop nets are used in the coastal of Southern and Cheju of Korea. Especially in the Cheju, the fishing gear of scoop nets consists of upper boom, lower boom, pressing stick and bag net. They are operated by fishing boats of 6 to 10 ton class and 8 persons on board. The booms are controlled by side drum, and the net and pressing stick are hauled by only human power in operating. Therefore this fishery needs to large labor and heavy human power and has much risk. Three kinds of hydraulic winding device which controls two booms was designed and manufactured to reduce heavy labor force of scoop nets, and trial in the sea was carried out to test their performances using the commercial fishing boats of 6 ton class. The proper capacity of hydraulic pump and motor were determined by model test of boom 1/5 scale. The results obtained are as follows, 1. Tension of boom which is being drawn was the strongest and 187.5kgf when the boom's end is in the depth of 4m under the water. 2. The hydraulic motor of the fittest kind of winder has the least leakage per time than the other kinds. 3. In the best type of several winder devices, when the pressure difference was fixed 130kg/2 for the safe fishery, the winding velocity of boom line was 2m/sec, is faster 0.48/sec than traditional fishing method and this winder can catch the anchovy of 1.6 tonnage. 4. As a result, the crew were decreased from 8 to 6 and the problem of heavy human power and risk on fishing operation were solved by using the this winder.

• 박성욱
• 배봉성
• 서두옥
