본 논문은 다양한 시설내에 적은 농도의 CO2 제거를 위한 선택적 CO2 흡수능력을 향상시킨 흡착제의 효율평가에 관한 것이다. 직경 4mm의 구형 흡착제는 시판용 제올라이트에 첨가제, 물, 바인더, LiOH를 섞어 제조하였다. 칼럼테스트에서 400분 이내에 90% 이상의 CO2흡착효율을 나타내었고, 흡착필터모듈 흡착능력을 평가하기 위해 회분식과 연속식타입의 챔버테스트가 시행되었다. 회분식테스트에서 30분 이내에 약 92%의 CO2가 제거되는 것을 확인하였다. 연속식테스트에서 30분 이내 70%의 CO2가 제거효율을 보였으며, 2,500ppm 이상의 CO2가 제거되는 것을 확인하였다. 재현성테스트를 수차례 수행한 결과 15일동안 1,000ppm 이상의 CO2가 연속적으로 제거됨을 보였다. TGA 분석법을 이용한 흡착량 분석에서 흡착제 g당 5.0mmol의 CO2를 흡착하는 것으로 나타났다. 본 연구에서 개발된 흡착제는 상온에서 저농도 CO2 실내환경에 적용가능한 것으로 판단된다.
In this study, CO2 adsorbent was developed for removing low concentration of CO2 in multiple-use facilities. The efficiency of the adsorbent which was improved selective CO2 adsorption capabilities was evaluated. The pellet type adsorbent was modified from a commercial zeolite with mixing LiOH, binder, additives, and H2O. Column tests showed over 90 % of CO2 was adsorbed within 400min. Chamber tests including batch and continuous types were performed for evaluating the adsorbent module. By batch tests, it was evaluated that about 92% of CO2 was removed within 30 min. By continuous tests, 70% of CO2 was removed within 30 min. It was analyzed that over 2,500 ppm of CO2 was continuously removed as shown chamber tests. The reproducibility tests repeatedly performed for 15 days shows that over 1,000 ppm of CO2 was continuously removed. Adsorption capacity of the developed adsorbent was 5.0mmol CO2/g adsorbent which was analyzed by TGA. It was estimated that the modified adsorbent was applicable to low CO2 concentration and low temperature of indoor environment.
