This paper proposes a method for generating radar images used in a ship handling simulator, which includes mathematical logics based on radar equations and information from Openflight format files. In order to make radar image much similar to that of real radar in PPI type, the proposed mathematical logic derives radar video signals under the consideration of not only the data form flight format file of simulation scenes, but also geographical radar's position. The proposed method is considered useful to make radar images in ship handling simulator with accuracy and reality.

• Min Jung
• Sin-Geol Lee
• Chae-Uk Song
