pp.197-204
회류수조에서의 대각도 정적(static) 모형실험을 통해 Manta형 무인잠수체에 작용하는 동유체력을 측정하였으며, 동유체력에 미치는 Reynolds수의 영향을 고찰하였다. 이를 위해 동유체력을 cross-flow drag과 양력(lift force)으로 성분 분석을 하였으며, 양력 성분에는 Reynolds수의 영향을 무시하고, cross-flow drag 성분에만 Reynolds수의 영향을 고려하였다. 그 후 이들 두 성분을 다시 합성함으로써 실물 무인잠수정에 작용하는 동유체력의 추정 기법을 제시하였다.
The authors adopt the Unmanned Undersea Vehicle(UUV), the shape of which is like a manta. They call here it Manta UUV. Manta UUV has been designed from the similar concept of the UUV called Manta Test Vehicle(MTV), which was originally built by the Naval Undersea Warfare Center of USA(Lisiewicz and French, 2000; Simalis et al., 2001; U.S. Navy, 2004). The present study deals with the effect of Reynolds numbers on hydrodynamic forces acting on Manta UUV at large angles of attack. The large angles of attack cover the whole range of 0 to ± 180 degrees in horizontal plane and in vertical plane respectively. Static test at large attack angles has been carried out with two Manta UUV models in circulating water channel. The authors assume that the experimental results of hydrodynamic forces (lateral force, yaw moment, vertical force and pitch moment) are analyzed into two components, which are lift force component and cross-flow drag component. First of all, Based on two dimensional cross-flow drag coefficient at 90 degrees of attack angle, the cross-flow drag component at whole range of attack angles is calculated. Then the remainder is assumed to be the lift force component. The only cross-flow drag component is assumed to be subject to Reynolds number.entstly the authors suggest the methodology to predict hydrodynamic derivertives acting on the full-scale Manta UUV.
