고무상 고분자인 PDMS (polydimethylsiloxane)에 HNT (halloysite nanotube)의 함량을 5, 10, 20, 30 wt%로 달리하여 PDMS-HNT 복합막을 제조하고, FT-IR, XRD, TGA, SEM에 의해서 막의 특성을 조사하였다. 기체투과 실험은 25°C, 3 kg/cm2 조건에서 수행하였고, PDMS-HNT 복합막의 HNT 함량 변화에 따른 H2, N2, CH4, CO2들의 기체투과도와 선택도를 조사하였다. H2, N2, CH4, CO2의 투과기체에 대해 HNT 함량이 0~30 wt% 범위에서 HNT 함량이 증가할수록 기체들의 투과도는 전체적으로 감소하는 경향을 보였다. 선택도(CO2/N2)는 14~44의 값을 보였고, 선택도(CO2/CH4)는 3.0~7.7의 값을 보였다.
PDMS (polydimethylsiloxane)-HNT (halloysite nanotube) composite membranes were prepared with different amounts tendency of HNT 5, 10, 20 and 30 wt% and rubbery polymer PDMS. The characteristics of these membranes were studied by FT-IR, XRD, TGA, and SEM. Gas permeation experiment were performed under condition of 25°C and 3 kg/cm2. Gas permeability of N2, H2, CH4, and CO2 and selectivity were investigated by increasing the amount of HNT con-tents in the PDMS. In H2, N2, CH4, and CO2 gases, as increasing HNT contents from 0 to 30 wt%, decreasing value of the permeability were observed. The selectivity of (CO2/N2) was shown in the range of 14 to 44 and the range of selectivity of (CO2/CH4) was 3.0 to 7.0.
