논문 상세보기
pp.1-8
본 연구에서는 유황을 폴리머화하여 내화학성능이 요구되는 구조물의 콘크리트 표면보호재로 활용할 수 있도록 성능을 검토하였다.평가 결과, 유황폴리머 표면도포재의 중력식 스프레이가 적절한 것으로 나타났으며, 도포횟수는 왕복 3회 이상 도포했을 때 1MPa 이상의 부착강도 확보가 가능하였다. 표면보호재가 도포될 콘크리트 표면조건은 상온조건 (20~30℃) 이상에서 높은 부착강도를 나타내었으며,온도가 높을수록 부착강도가 증가하였다. 표면보호재의 채움재 혼입량에 따른 강도특성 평가결과, 20~40% 정도 혼입된 채움재는 유황폴리머의 수축을 저감시키는 효과를 나타내어 강도 향상에 기여하였다. 또한, 플라이애시 보다는 규사 혼입시 부착강도가 높았고, 동시 혼입시가장 우수한 부착강도 특성을 나타내었다. 화학저항성은 플라이애시 및 규사를 각각 20% 대체한 배합에서 부착강도 저하가 최소로 되어우수한 내화학성을 나타내었다. 염소이온 침투에 대한 성능평가를 수행한 결과, 표면보호재를 도포하지 않은 시험체에 비하여 유황폴리머표면보호재를 도포한 경우, 29~48% 정도 염소이온침투저항성이 증대되었다. 표면보호재의 도포조건, 압축강도, 부착강도, 화학저항성, 염해저항성 등을 모두 고려하여 볼 때, 본 연구범위에서는 유황폴리머에 채움재로서 규사와 플라이애시를 각각 20%씩 대체하는 것이 적절한수준인 것으로 판단된다.
Structures requiring chemical resistance are usually coated with surface protecting agents, but the cost for maintenance and re-construction is incurred due to the low durability. Therefore, in this study, sulfur was polymerized and the performance was examined so that it could be used as the concrete surface protecting agents for structures requiring chemical resistance.The evaluation results indicated that for the spray of the sulfur polymer surface coating agents, the application of the gravitytype was appropriate; and for the number of coating times, about 3 cycle spray gave the best results. For the surface condition ofthe concrete to be coated with the surface protecting agents, outstanding quality was obtained above room temperature (20~30℃),and the bond strength increased as the temperature increased. The evaluation results of the strength characteristics depending on the filler content of the surface protecting agents indicated that about 20~40% filler mixing contributed to the strength improvementas it reduced the shrinkage of the sulfur polymer. Also, the mixing of silica showed larger increase in the bond strength than the mixing of fly ash, and the most outstanding bond strength characteristics could be obtained by the mixing of both silica and flyash. In the case of the chemical resistance, the strength reduction was minimized and outstanding chemical resistance was obtained when the fly ash and silica were substituted by 20%, respectively. The performance evaluation of the chloride ion penetration indicated that for the specimens coated with the sulfur polymer surface protecting agents, the chloride ion penetration resistance increased by 29~48% compared to the specimen without the coating of the surface protecting agent. The examination of the coating condition of the surface protecting agents, compressive strength, bond strength, chemical resistance, and salt damage resistance indicated that in the range of this study, the optimal level was when the silica and fly ash were substituted by 20%, respectively, as the filler for the sulfur polymer.
2. 사용재료 및 실험방법
2.1 사용재료
2.2 실험방법
2.3 배합
3. 시험결과 및 고찰
3.1 도포조건 평가
3.2 배합조건에 따른 특성평가
4. 결 론
감사의 글
References
