TiC-21mol% Mo solid solution (δ-phase) and TiC-99 mol% Mo solid solution (β-phase), and TiC-(80~90)mol%Mo hypo-eutectic composite were deformed by compression in a temperature range from room to 2300 K and in a strain raterange from 4.9×10−5 to 6.9×10−3/s. The deformation behaviors of the composites were analyzed from the strengths of theδ- and β-phases. It was found that the high strength of the eutectic composite is due primarily to solution hardening of TiCby Mo, and that the δ-phase undergoes an appreciable plastic deformation at and above 1420 K even at 0.2% plastic strainof the composite. The yield strength of the three kinds of phase up to 1420 K is quantitatively explained by the rule of mixture,where internal stresses introduced by plastic deformation are taken into account. Above 1420 K, however, the calculated yieldstrength was considerably larger than the measured strength. The yield stress of β-phase was much larger than that of pure TiC.A good linear relationship was held between the yield stress and the plastic strain rate in a double-logarithmic plot. Thedeformation behavior in δ-phase was different among the three temperature ranges tested, i.e., low, intermediate and high. Atan intermediate temperature, no yield drop occurred, and from the beginning the work hardening level was high. At the testedtemperature, a good linear relationship was held in the double logarithmic plot of the yield stress against the plastic strain rate.The strain rate dependence of the yield stress was very weak up to 1273 K in the hypo-eutectic composite, but it becamestronger as the temperature rose.

• Shin, Soon-Gi(Department of Advanced Materials Engineering, College of Samcheok, Kangwon National University)
