pp.143-150
At present, the actual condition is that Korean modular structures are limited to a low rise detached house and military barracks. And there is no standardized structural design method of stacked modular structure. Accordingly, in general, they don't review impact force in the stage of stacking and installing a module, the effect which wind load has on a structure in the stage of lifting, and inertial force occurring in the stage of lifting or transporting a module in the process of constructing a structure.
Therefore, this study investigated the construction method of modular system to be studied in stages, and decided on the position to which load was applied and boundary condition in structural analysis at each construction stage. Besides, inertial force according to each speed was calculated in the lifting and wheeled transport of module. And we calculated impact load according to lifting speed in module stacking and installation work and wind load due to instantaneous wind speed in the installation work by lifting. On the basis of the suggested method, in the modular system to be studied, it carried out review of structure by changing determining conditions of load being applied by construction stage, such as in the stage of lifting, in the stage of transport, and in the stage of installation, and drew construction conditions securing stability structurally.
2. 검토대상 모듈러 시스템
3. 시공단계 구조성능 평가방안
3.1 양중작업 시 급제동에 의한 관성력 고려방안
3.2 양중 설치작업 시 풍속에 따른 고려방안
3.3 운송시 급제동에 의한 관성력 고려방안
3.4 모듈설치시 발생하는 충격하중 고려방안
3.5 시공단계에 대한 부재 안전성 및 변형검토
4. 검토대상 모듈러 시스템의 시공조건 검토
4.1 구조해석모델의 수립
4.2 양중작업 시 적정 양중속도 검토
4.3 양중작업 시 적정 순간풍속 검토
4.4 차량 운송시 적정 속도 검토
4.5 설치작업 시 적정 설치속도 검토
5. 결 론
감사의 글
References
