In this paper, the control technique of the stepping motor using back electromotive force(B-EMF) without encoder is investigated. The stepping motor generally uses the rotary encoder to detect the rotor position. Since this method increases the cost and the motor configuration size, the new closed-loop control method applied for the B-EMF was implemented by using current detect circuit, AD-converter, and micro controller unit(MCU). The contorl loop of stepping motor became very simplified. The current change of stepping motor measured by the amplifier was measured and analyzed, when the missing step is occurred. Based on the data from current feedback, position errors were compensated and confirmed by using AD-converter.

1. 서론
 2. 스테핑모터
  2.1 역기전력
  2.2 제어방법
 3. 실험장치 설계 및 구성
  3.1 제어 알고리즘
  3.2 제어 및 역기전력 측정 회로
  3.3 2상 스테핑모터 제어시스템
 4. 결론
 5. References

• 임성빈(조선대학교 기계공학과) | Sungbeen Im Corresponding Author
• 정상화(조선대학교 기계공학과) | Sanghwa Jeong
