선박이 운항 중 해난 사고가 발생하여 선원이나 승객이 물에 빠지는 경우 신속히 이들을 구조하는 것은 매우 중요한 일이다. 대부 분의 해난 사고의 경우 물에 빠진 사람이 구명조끼를 입고 있으므로, 구명조끼에 GPS 및 Cospas-Sarsat 통신을 위한 모듈이 내장된다면 구 조가 용이할 것이다. 본 논문에서는 구명조끼에 내장이 가능하며 GPS 및 Cospas-Sarsat 통신을 위한 이중대역 안테나를 개발하고자 한다. 안테나는 두께 0.2mm 인 FR4 기판을 사용하여 유연성을 확보하였고, 1.575 GHz와 406MHz에서 동작하며, 구명조끼의 어깨 부근에 장착이 될 수 있는 안테나를 설계하였다. GPS 통신용 안테나는 원형편파 특성을 갖는 링 슬롯 안테나로 구현하였고, 미앤드 형태의 선형 편파 안테 나를 Cospas-Sarsat 통신용으로 사용하였다. 단일 마이크로스트립 선로를 통해 급전이 이루어지며, 두 공진 안테나간의 상호 간섭을 최소화 하기 위해 개방형 스터브를 사용하였다. 제작한 안테나를 구명조끼에 장착하여 반사손실 측정을 통해 GPS 및 Cospas-Sarsat 주파수에서 안 테나의 성능을 확인하였다.
When the crew or passengers fall into the water due to marine accident of vessel, it is very important to rescue them quickly. In the case of marine accidents, most people in distress have been wearing a lifejacket, so if the GPS and Cospas-Sarsat communication module will be integrated within the lifejacket, it is easy to rescue them. In this paper, development of the dual band lifejacket-integrated antenna for GPS and Cospas-Sarsat communication is discussed. The antenna with the FR-4 substrate of 0.2mm thickness for flexibility was designed that it can be fitted close to the shoulder of the life jacket and operate at 1.575GHz and 406MHz. The GPS communication antenna was implemented with a ring-slot antenna having a circular polarized characteristic and a meander type linear polarized antenna is used as Cospas-Sarsat communication. The two antennas are fed by a single microstrip line and an open stub is used to minimize the mutual interference between the two antennas. The performance of the fabricated antenna attached to the life vest is confirmed by the measurement of the return loss at GPS and Cospas-Sarsat frequency bands.
