pp.135-141
PURPOSES : The lack of details of design guideline for zig-zag shaped section approaching central bus stop leads an traffic accident proneness. So, this study analysed the geometric elements of central bus stop area in terms of vehicle dynamics and suggested design alternatives.
METHODS: The study analysed a dynamic behaviour of bus moving in and out of zig-zag shaped section using Auto-Turn under scenarios. Based upon dynamic analysis, the study found out the width of overtaking lane is the most influential factor for a safe moving at zig-zag alignment.
RESULTS : The width of overtaking lane at design speed of 40, 50, and 60 km/h respectively was suggested given taper ratio of 1 to 10 required for Bus Rapid Transit (BRT), and the lane width is not wider than 4.0m which possibly makes two vehicles using the same lane. Also, the width of overtaking lane which mitigates the taper ratio was suggested with the same restriction about the maximum lane width.
CONCLUSIONS: The results of the study can be used to prepare a design guideline on zig-zag shaped alignment of central bus exclusive lanes. The more stable moving is expected by applying the design alternatives suggested, therefore the lower rate of traffic crashes at the vicinity of central bus stops.
