Bridge construction cost estimates have generally been conducted by using historial unit-price(per meter or square meter). The traditional estimating method based on unit-price references can never completely reflect the specialty of cable supported bridge. In this paper, we have developed the system for supporting the approximate construction cost and the quantity estimation based on 3D model information in the pre-project planning phase of 3-span continuous suspension bridge with 2-pylons. First of all, we’d analyzed the design information (such as structural design report, blueprint and quantity) and the real cost data from the existing suspension bridges and derived the design variables of the bridges. We developed the BIM wizard that generates a suspension bridge model parametrically based on derived design variables. The principle material quantities of suspension bridge are calculated directly from 3-dimensional bridge model built by using the BIM wizard. We have established the system that the construction cost can be estimated more specific than the traditional estimating method.

1. 서 론
2. 주요 부재별 단면설정
3. 시스템 인터페이스 설계 및 구현
4. 결 론
References

• 박원태(공주대학교 건설환경공학부 교수) | Park, Weon-Tae
• 천경식(포스코건설 R&D센터 책임연구원) | Kyoung-Sik Chun Corresponding author
