The proposed hybrid damper installs at a coupling beam and consists of a high-damping rubber (HDR) and steel pin. The proposed hybrid damper adopted a pin-lock system acts as a viscoelastic damper under wind load (small displacement) while it behaves as a hysteretic damper under earthquake load (large displacement).
In this paper, the pin-lock mechanism and structural performance of the proposed hybrid damper is evaluated through experiment. Experiments were carried out with the variables which displacement, loading frequency and steel pin quantities were used. Test results showed that the pin-lock mechanism and the performance of the hybrid damper under a large displacement were verified. Also equivalent damping ratios of HDR were increasing at a small displacement as displacement amplitudes were increasing. However HDR did not depend on frequency,

1. 서론
 2. 핀-락 메커니즘
 3. 실험계획
  3.1 실험체 설계 및 계측계획
  3.2 실험체 세팅 및 가력계획
 4. 실험결과 및 분석
  4.1 전체거동
  4.2 핀-락 메커니즘 작동 전 거동
  4.3 핀-락 메커니즘 작동 후 거동
 5. 결론
 References

• 김지영(㈜대우건설 기술개발팀 수석연구원) | Kim Ji-Young
• 정인용(DRB동일 면진제진사업팀 과장) | Jung In-Yong
• 김형근(서울주택도시공사 도시연구원 연구위원) | Kim Hyung-Geun
• 김도현(경기과학기술대학교 건축인테리어과) | Kim Do-Hyun 교신저자
