pp.213-221
The study analyzed performance assessment factors of VOCs odor sensors from 3 different manufacturers, such as minimum detection limit, humidity stability and temperature stability. Through the minimum detection limit assessment, it was found that a VOCs sensor was able to detect TVOCs at the concentration of 5 ppb. The standard deviation ratio was over 10%, and it increased as humidity rose. The range of temperatures in which the VOCs odor sensor using photoionization could operate was between 25oC and 40oC, and the sensor output values were unstable at low temperatures. In terms of the temperature stability of the metal oxide semiconductor sensor for measuring complex odors, the sensor output values dropped considerably to 0~10oC, and were similar to the concentrations of odorous gases generated at 25oC. The results of the test of VOCs odor sensor outputs after temperature and humidity pre-treatment revealed that the respective stable output values at 50% humidity and 25oC were similar to the concentrations of manufactured odors. In terms of temperature and humidity stability of the VOCs odor sensors, all target VOCs substances had stable output values at 25oC to 40oC and at 50% to 65% relative humidities, and unstable values at low temperatures and high humidities. Therefore, the implementation of pre-treatment systems including temperature and humidity correction (25~40oC, 50~65% RH) is required for the stable use of VOCs odor sensors.
2. 연구내용 및 방법
2.1 VOCs 악취센서의 온도와 습도에 따른 감지특성
2.2 VOCs 악취센서의 온도와 습도에 따른 안정성
3. 연구결과 및 고찰
3.1 VOCs 악취센서의 최소검출한도
3.2 VOCs 악취센서의 온도의 안정성
3.3 VOCs 악취센서의 습도의 안정성
4. 결 론
References
