The BCBJ (Back Contact and Back Junction) or back-lit solar cell design eliminates shading loss by placing the pn junction and metal electrode contacts all on one side that faces away from the sun. However, as the electron-hole generation sites now are located very far from the pn junction, loss by minority-carrier recombination can be a significant issue. Utilizing Medici, a 2-dimensional semiconductor device simulation tool, the interdependency between the substrate thickness and the minority-carrier recombination lifetime was studied in terms of how these factors affect the solar cell power output. Qualitatively speaking, the results indicate that a very high quality substrate with a long recombination lifetime is needed to maintain the maximum power generation. The quantitative value of the recombination lifetime of minority-carriers, i.e., electrons in p-type substrates, required in the BCBJ cell is about one order of magnitude longer than that in the front-lit cell, i.e., 5 × 10−4 sec vs. 5 × 10−5 sec. Regardless of substrate thickness up to 150 μm, the power output in the BCBJ cell stays at nearly the maximum value of about 1.8 × 10−2 W·cm−2, or 18 mW·cm−2, as long as the recombination lifetime is 5 × 10−4 s or longer. The output power, however, declines steeply to as low as 10 mW·cm−2 when the recombination lifetime becomes significantly shorter than 5 × 10−4 sec. Substrate thinning is found to be not as effective as in the front-lit case in stemming the decline in the output power. In view of these results, for BCBJ applications, the substrate needs to be only mono-crystalline Si of very high quality. This bars the use of poly-crystalline Si, which is gaining wider acceptance in standard front-lit solar cells.

• Kwang Su Choe(Department of Electronic Materials Engineering College of Engineering The University of Suwon Hwaseong-si, Gyeonggi-do 18323, Republic of Korea)
