pp.759-769
본 논문에서는 12펄스 정류기의 커패시터 중앙 DC버스에 개선된 보조전원장치를 설치하는 방법을 제안하였다. 11차 및 13차 고조파가 감소하는 이론적인 배경을 다루었으며 부하전류의 크기, 전원전압의 위상 및 크기, 커패시터 전압에 따라 개선된 보조전원의 파형 및 크기가 어떻게 제어되어야 하는지를 제시하였다. 기존의 구형파 보조전원장치를 적용한 경우는 전 영역에서 고조파 왜형률이 6~60[%]로 큰 편차를 보이지만 본 눈문에서 제안하는 개선된 보조전원장치를 적용한 경우 저 부하에서 고 부하에 이르는 전 영역에서 57~71[%] 라는 안정되고 뛰어난 고조파 왜형율 저감 효과를 보인다. 특히 10[%] 부하상태에서 기존방식은 고조파 왜형율 저감효과가 6[%]로 효과가 거의 없지만 제안된 방식은 71[%]라는 놀라운 저감성능을 보여주고 있다. 소프트웨어 PSIM을 활용하여 컴퓨터 시뮬레이션을 통해 제안된 방식의 유효성을 입증하였다.
Diode rectifiers are very popular in industry. However, they include large low-order harmonics in the input current and do not satisfy harmonic current content restrictions. To reduce the harmonics to the power system, several methods have been introduced. It is heavy and expensive solution to use passive filters as the solution for high power application. Another solution for the harmonic filter is utilization of active filter, but it is too expensive solution. Diode rectifiers with configurations using switching device have been introduced, but they are very complicated. The combined 12-pulse diode rectifier with the square auxiliary voltage supply has been introduced. It has the advantages that auxiliary circuit is simple and inexpensive compared to other strategies. The advanced auxiliary voltage supply in this thesis is presented as a new solution. When the square auxiliary voltage supply applied, the improvement of THD is 6~60[%] in whole load range. But when the advanced auxiliary voltage supply applied, it shows stable and excellent reduction effect of THD as 57~71[%]. Especially, for the case with 10[%] load factor, reduction effect of THD has little effect as 6[%] in the case of inserting a square auxiliary voltage supply. But when the proposed new solution applied, reduction effect has excellent effect as 71[%]. Theoretical analysis of the combined 12-pulse diode rectifier with the advanced auxiliary voltage supply is presented and control methods of the auxiliary supply is proposed. The reduction in the input current harmonics is verified by simulation using software PSIM.
