본 연구는 LS-DYNA 971 을 이용하여 내빙 구조 선박과 빙산 모형 간의 충돌 시험을 수행 후 북극해 운항 선박의 내빙 능력을 분석하였다. 국제선급연합회(IACS)의 Unified Requirements for Polar ship(URI) 규정을 바탕으로 FEM 선박 모형에 내빙 구조를 적용하였으며, 빙산 모형에는 Elastic-perfect plastic 물성과 Tsai-Wu 항복 곡면을 적용하였다. 또한 실험 결과 비교를 위하여 내빙 구조를 갖추지 않은 일반 선박 모형과의 충돌 시험도 수행하였다. 실험 결과 일반 구조 선박의 구형 선수에 빙산 모형에 의해 움푹 들어간 약 1.8 미터 깊이의 선체 손상이 발생하였으나, 내빙 구조 선박의 충돌에서는 약 1.0 미터 깊이의 선체 손상만이 발생하였다. 또한 일반 구조 선박과 충돌한 빙산모형은 원형의 상태를 거의 유지한 반면, 내빙 구조 선박과 충돌한 빙산 모형은 내빙 구조의 구형 선수에 의해 빙산이 일부 파괴되는 현상이 발견되었다.

Shipping activities have become possible in the Arctic Ocean due to melting ice by global warming. An increasing number of vessels are passing through the Arctic Ocean consequently bringing concerns of ship-iceberg collisions. Thus, most classification societies have implemented regulations to determine requirements for ice strengthening in ship structures. This paper presents the simulation results of an ice-strengthened polar class ship after an iceberg collision. The ice-strengthened polar class ship was created in accordance with the Unified Requirements for a Polar-Ship (IACS URI). An elastic-perfect plastic ice model was adopted for this simulation with a spherical shape. A Tsai-Wu yield surface was also used for the ice model. Collision simulations were conducted under the commercial code LS-DYNA 971. Hull deformations on the ice-strengthened foreship structure and collision interaction forces have been analysed in this paper. A normal-strength ship structure in an iceberg collision was also simulated to present comparison results. Distinct differences in structural strength against ice impact forces were shown between the ice-strengthened and normal-strength ship structures in the simulation results. About 1.8 m depth of hull deformation was found on the normal ship, whereas 1.0 m depth of hull deformation was left on the ice-strengthened polar class ship.

• Sunghyug Kim(State Key Laboratory of Ocean Engineering, Shanghai Jiao Tong University) | 김성혁
• Yu Luo(State Key Laboratory of Ocean Engineering, Shanghai Jiao Tong University) | 라우 Corresponding Author
• Chu Shi(State Key Laboratory of Ocean Engineering, Shanghai Jiao Tong University) | 석초
• Chang-Hyun Lee(Mokpo National Maritime University) | 이창현
