The brake systems are composed of brake disc, brake pad and caliper and, these three parts play an important role for braking. In this study, heat fluid analysis is conducted for five different ventilated disc models, and two piece brake disc model separated in rotor and housing is used. In this case, each model has a different number of holes and vent shape. The basic heat flux and braking power equations are applied for the heat fluid analysis. The cooling performance with/without the braking operation is also analyzed for given five models where the material properties and boundary conditions are set to be identical. From our analysis results, it is found that the number of disc holes and ventilated pins strongly influences on the cooling performance.

• 박기완(Kongju national university) | Ki-Wan Park
• 남재현(Kongju national university) | Jae-Hyeon Nam
• 강재영(Kongju national university) | Jae-Young Kang
• 김영식(Hanbat national university) | Young-Shik Kim
• 이재복(Stolz company) | Jae-Bok Lee
• 유봉조(Hanbat national university) | Bong-Jo Ryu Corresponding Author
