Recently, the air quality issue came to the fore to the occupants of indoor areas with the detection of a large amount of indoor air pollutants such as formaldehyde that causes headache and atopic dermatitis. In order to address this issue, the use of indoor air purifying plants is considered positively as an ecological improvement option. However, the objective performance verification on indoor air-conditioning air volume has not been sufficient. This study aims to verify possible linkage with a building’s air conditioning equipment in order to optimize indoor air-conditioning effects by vegetation bio-filters. To this end, 4 different types of air filter material and AHU (Air Handling Unit) system were linked under air conditions of total wind volume of 400, 600, 800, 1,000 CMH and pressure loss by material was monitored objectively. Finally, material-specific power consumption for system operation was calculated to review energy efficiency. As for pressure loss by material, in terms of total wind volume of 800±1.8 CMH, Pre filter was lowest at –11.69 mmAq and LMF-based vegetation mat was highest at –219.94 mmAq. Based on this, as for material-specific power consumption, the Pre filter, which has the lowest pressure loss, was expected to have power consumption 94.7% lower than the LMF-based vegetation mat.

Introduction
 Theoretical Consideration
  Vegetation Bio-filter Technology
  Performance Standard of AHU Air Purifying Filter
  Differential Pressure and Pressure Loss Measurement Theory
 Study Content and Method
  Study Procedure
  Design and Development of Experiments
  Experimental conditions per vegetation bio-filter material
  Monitoring Design
  Calculating AHU energy consumption linked with pressure loss
 Conclusion and Consideration
  AHU operation environment configuration for pressure loss measurement
  Reference Pressure Loss according to Static Pressure in the Experiment
  Material-Specific Pressure Loss Evaluation
  Energy Consumption of AHU by Material and Assessment
 Conclusions
 References

• Tae-Han Kim(Department of Environmental Landscape Architecture, Sangmyung University) Corresponding author
• So-Dam Lee(Department of Environmental Landscape Architecture, Graduate school, Sangmyung University)
• Sung-Eun Park(College of General Studies, Sangmyung University)
