Shape memory alloys(SMAs) have revolutionized the material engineering sciences as they exhibit exclusive features i.e. shape memory effect(SME) and super-elasticity. SMAs are those alloys that when deform return to their predeformed shape upon heating, they also restore their original shape by removing the load. Research on properties of newly advent of several types of ferrous based shape memory alloys(Fe-SMAs), shows that they have immense potential to be the counterpart of Nitinol(NiTi-SMA). These Fe-SMAs have been used and found to be effective because of their low cost, high cold workability, good weldability & excellent characteristics comparing with Nitinol(high processing cost and low cold workability) SMAs. Some of the Fe-SMAs show super-elasticity. Fe-SMAs, especially Fe-Mn-Si alloys have an immense potential for civil engineering structures because of its unique properties e.g. two-way shape memory effect, super elasticity and shape memory effect as well as due to its low cost, high elastic stiffness and wide transformation hysteresis comparative to Nitinol. Further research is being conducted on SMAs to improve and impinge better attributes by improving the material compositions, quantifying the SMA phase transition temperature etc. In this research pre-existing Fe-SMAs are categorised and collected in a tabulated form. An analysis is performed that which category is mostly available. Last 50 years data of Fe-SMA publications and US Patents is collected to show its importance in terms of increasing research on such type of alloys to invent different compositions and applications. This data is analysed as per different year groups during last 50 years and it was analysed as per whether the keywords exist in title of an article or anywhere in the article. It was found that different keywords related to Fe-SMAs/categories of Fe-SMAs, almost don’t exist in the title of articles. However, these keywords related to Fe- SMAs/categories of Fe-SMAs, exist inside the article but still there are not too many publications related to Fe-SMAs/categories of Fe-SMAs.

Abstract
 1. Introduction
 2. Types of Ferrous based Shape Memory Alloys
  2.1 FeMnSi based shape memory alloys
  2.2 FeNiCo based shape memory alloys
  2.3 FeMnAl based shape memory alloys
  2.4 Ferromagnetic shape memory alloys
 3. Properties of Fe-Based SMA
  3.1 Recovery stresses
  3.2 Corrosion resistance
  3.3 Weldability
  3.4 Production
  3.5 Workability at room temperature
 4. Results & Discussions
  4.1 Fe-SMA Types and properties
  4.2 Importance of Fe-SMAs
 References

• Rana Atta Ur Rahman(Department of Mechanical Engineering, OvGU, Magdeburg, Germany, Department of Mechanical Engineering, UET, Taxila, Pakistan) Corresponding author
• Daniel Juhre(Department of Mechanical Engineering, OvGU, Magdeburg, Germany)
• Thorsten Halle(Department of Mechanical Engineering, OvGU, Magdeburg, Germany)
