In this study, the structural analysis was performed by using Solidworks program to investigate the stress and displacement characteristics of upper desk and table arm depending on the types and positions of load applied to the height-adjustable table(Cases 1, 2, 3, 4). The simulation was used to model the table and create the mesh for computational analysis. The height-adjustable table consists of three parts, upper desk, table arm and support body. Case 3 with the side concentrated load showed the maximum stress and maximum displacement at table arm and upper desk. From the stress and displacement characteristics of the upper desk and table arm, the stresses at the bending part of table arm and the deflection at the front part of upper desk were the greatest.

ABSTRACT
 1. 서 론
 2. 해석 모델 및 구속조건
  2.1 해석모델
  2.2 구속조건
 3. 전산해석 결과
  3.1 Upper desk 전체 면에 분포하중 인가
  3.2 Upper desk 앞면에 분포하중 인가
  3.3 Upper desk 측면에 집중하중 인가
  3.4 Upper desk 중앙에 집중하중 인가
 4. 결 론
 References

• 왕쩐후안(Department of Mechanical Engineering, Sunmoon University) | Zhen Huan Wang
• 권영철(Department of Mechanical Engineering, Sunmoon University) | Young-Chul Kwon Corresponding Author
