An AVL research engine, type 520, is modified to adapt to the 3.5L four-valve SI engine. With these given engine configurations, a test rig is constructed which allows easy changing of the different pistons and engine heads with a motoring capacity up to 3500 rpm. Nearly complete optical access to the inside of the cylinder is obtained by installing a transparent quartz cylinder on an AVL single cylinder engine. To avoid lubrication and to minimize scratches in the quartz cylinder the piston rings are made of Rulon-LD. With this experimental engine, researches for the in-cylinder flow characteristics by changing the induction system have been carried out using the laser based flow diagnostic techniques. In accordance with the previous result, it is evident that larger sized particles would be required in order to observe the flow characteristics of interest. The flow visualization taken with microballoon particles shows significant improvement. This provide detailed information.

ABSTRACT
 1. 서 론
 2. 실험장치 제작
  2.1 실험장치의 구성
  2.2 석영 실린더와 피스톤 링 제작 및 설치
  2.3 윤활 시스템 제작
 3. 결과 및 고찰
 4. 결 론
 References

• 유성출(Halla University) | S. C. Yoo Corresponding Author
