pp.1-8
PURPOSES : The purpose of this paper is to develop an evaluation method for aged reclaimed asphalt pavements using RAP mortar specimen and FTIR method.
METHODS: To evaluate the low-temperature behavior of aged reclaimed asphalt pavements, an indirect tensile strength test was adopted with an RAP mortar specimen. The RAP mortar specimen without a rejuvenator was fabricated with two fine aggregate types as a function of passing sieve sizes. The fabricated RAP mortar specimen was frozen for 24 h at -20℃. The indirect tensile strength was measured as a function of different absolute viscosities. The indirect tensile strength and displacement were varied as functions of the dosage of the rejuvenator. The spectroscopy analysis of four asphalt binders was performed under attenuated total reflection. The four asphalt binders comprised of a virgin binder, two extracted RAP binders, and a mixed virgin and extracted RAP binder. To evaluate the oxidation of the binder, the carbonyl index was calculated.
RESULTS : The four extracted RAP binders were measured with an extremely wide range of absolute viscosity from 30,000 poise to 170,000 poise. The indirect tensile strength of the RAP mortar decreased as the absolute viscosity increased. This means that at lower temperatures, the indirect tensile strength can indicate the oxidation of RAP. Also, the indirect tensile strength and displacement changed sensitively as the dosage of the rejuvenator was changed. Based on the FTIR principle, a good relation was observed between the dosage of the rejuvenator and the FTIR absorbance peak. It can be used to estimate the dosage of the rejuvenator in hot reclaimed asphalt mixture. Also, the carbonyl index of the RAP binder was calculated to evaluate asphalt oxidation using the FTIR principle.
CONCLUSIONS : There is a good relation between the indirect tensile strength of RAP mortar and its absolute viscosity. This indicates that RAP mortar can be used to estimate the properties of aged RAP. Also, the usage of rejuvenator can be evaluated with both the indirect tensile strength and FTIR absorbance peak. The carbonyl index can be used to predict asphalt oxidation.
1. 서론
3. 실험 방법
3.1. 노후 아스팔트 바인더 추출 및 절대점도 측정
3.2. RAP Mortar를 이용한 마샬공시체 제작
3.3. FTIR 분석
4. 시험결과
4.1. 절대 점도 측정 결과
4.2. RAP Mortar 간접인장강도 결과
4.3. 재생첨가제 사용에 따른 간접인장강도 특성
4.4. FTIR을 활용한 재생첨가제량 예측식 도출
4.5. FTIR를 이용한 산화도 측정
5. 결론
REFERENCES
