The clamping of torque shear high strength bolt is induced when the pin-tail is broken. Sometimes the clamping forces on slip critical connections do not meet the required tension due to torque coefficient dependent on conditions such as outdoor temperature, moisture and dust. From this study, the clamping forces of torque shear bolts at indoor conditions were compared with actual data investigated from 24 construction sites last five years. Similarly to foreign literature results, torque shear bolts showed that torque coefficients were fluctuated greatly by temperature conditions. The range of torque coefficient at indoor conditions was analyzed from 0.126 to 0.158 while tensions were indicated from 179 to 192 Nㆍm. Instead, the range of torque coefficient at site conditions was analyzed from 0.118 to 0.152. Based on this test, the variable trends of torque coefficient subjected temperature can be traced via statistic regressive analysis. In case of indoor conditions, it was showed that the variable of torque coefficient was 0.13% per 1℃, while the variable at actual site conditions reached 2.73% per 1℃.
1. 서 론
2. 일본 문헌분석
3. 실내 실험 및 현장 측정
4. 결론
References
