본 연구의 목적은 여러 가지 하지입식검사에 적용할 수 있는 Multi-Function Device(MFD)를 제작하여 기 존에 사용하던 Weight Bearing Platforms(WBPs)들과 X 선 영상의 비교를 통해 임상 활용을 제안하고자 한 다. MFD는 단상(보조기구)를 이용한 Weight Bearing Foot/Ankle, Hindfoot Alignment View 검사시 X선 장치 의 X선 관구의 최하 조절 높이를 고려하여 제작하였다. 그리고 Foot/Ankle Phantom으로 MFD와 WBPs에서 Weight Bearing Lateral Foot과 Hindfoot Alignment View를 검사하여 X선 영상의 해상력을 Quick MTF(modula tion transfer function)프로그램으로 비교하였다. 연구결과 MFD와 WBPs에서 검사한 두 가지 영상 모두 MTF 50(50% Contrast Spatial Frequency)과 10-90%(10-90% of Maximum Energy Rise Distance) Rise의 C/P(Cycles Pe r Pixel)평균과 LPH(Lines Per Image Height)평균 모두 유의한 차이는 없었다(p>0.05). 연구에서 제작한 MFD 는 환자의 안전과 여러 가지 검사를 복합적으로 수행 할 수 있는 유용한 보조기구로 임상 활용을 제안한 다. 또한 정책적으로 보조기구의 활용을 권장한다면 전문 업체의 활성화를 돕는 길이며 의료의 질도 더욱 향상할 수 있을 것이다.

The purpose of this study is to manufacture a multi-function device (MFD) which can be applied to various types of weight-bearing view of the lower leg, and to compare the results with the images from the existing weight-bearing platforms (WBPs), thereby suggesting a clinical utilization. The MFD was manufactured, by considering the minimum adjustable heights of the platform for weight-bearing foot/ankle, platform for hindfoot alignment view, and X-ray tube of the X-ray device. A foot/ankle phantom was used to take the images of weight-bearing lateral foot in MFD and WBPs to compare the resolutions of the X-ray images using a quick modulation transfer function (MTF) program. Between both the images taken from the MFD and WBPs, there was no statistically significant difference found in the mean cycles per pixel (C/P) and the lines per image height (LPH) of the 50%-Contrast Spatial Frequency (MTF50), and 10-90% of Maximum Energy Rise Distance (10-90%), where p>0.05. The MFD is suggested for its clinical trial as a useful positioning device that can secure the patient’s safety and manifoldly perform various inspections. Also, the recommendation of the positioning device as a policy can activate dedicated manufacturers, while also improving the quality of medical services.

ABSTRACT
Ⅰ. INTRODUCTION
Ⅱ. MATERIAL AND METHODS
    1. Design and Manufacture of MFD
    2. Comparison of X-ray image quality betweenMFD and WBPs
Ⅲ. RESULT
    1. Comparison of resolutions of weight-bearing lateral foot images
    2. Comparison of resolutions of hindfoot alignmentview images
Ⅳ. DISCUSSION
Ⅴ. CONCLUSION
요 약

• Jong-Won Gil(Division of Medical Radiation, Center for Disease Prevention, Korea Centers for Disease Control and Prevention) | 길종원
• Kwang-Sung Lee(Department of Radiology, Daejeon Health Institute of Technology) | 이광성 Corresponding Author
