We present our analysis results for an updated orbital ephemeris for the dipping low mass X-ray binary 4U 1624-49, using the light curve collected by the All Sky Monitor (ASM) on board the Rossi X-ray Timing Explorer (RXTE) and the Monitor of All-Sky X-ray Image (MAXI). To make clear dip profiles, the light curve from the ASM and the MAXI were divided into ten 500d segments and four 400d segments for ASM and MAXI light curves, respectively, and folded with the linear ephemeris proposed by Smale et al. (2001). The phases of dip centers were determined by the method adopted from Hu et al. (2008). The phase drift was then fitted with a linear function. We obtained an updated orbital period of 0.869896(1) d and a phase zero epoch of JD 2450088.6618(57). No clear orbital period derivative is detected with a 2-sigma upper limit of 1.4 X 10-6(yr)-1 from a quadratic curve fitting of the dip phase evolution.

ABSTRACT
1. INTRODUCTION
2. OBSERVATIONS
    2.1. ASM
    2.2. MAXI
3. DATA ANALYSIS
4. SUMMARY
REFERENCES

• Nai-Hui Liao(Institute of Astronomy, National Central University)
• Yi Chou(Institute of Astronomy, National Central University)
• Hung-En Hsieh(Institute of Astronomy, National Central University)
• Po-Sheng Chuang(Institute of Astronomy, National Central University)
