본 연구에서는 열유도상분리법(thermally induced phase separation)을 사용하여 제조한 플라워 형태의 단면을 갖는 PVDF [poly(vinylidene fluoride)] 중공사 분리막에 대한 친수화 코팅과 그에 따른 특성평가에 대한 연구를 수행하였다. 연구에 사용한 중공사 분리막은 (주)퓨어엔비텍에서 제조한 PVDF 소재의 분리막이었으며, 친수화 코팅 실험은 PEBAX 1657, 2533, 3533의 공중합체 고분자를 사용하여 농도가 다른 용액을 제조 후 딥 코팅 방법을 이용하여 실시하였다. 친수화 코팅이 된 중공사 분리막은 친수화 정도를 파악하기 위하여 SEM 촬영 및 접촉각 측정을 실시하였다. SEM 촬영 결과 코팅의 농도가 증가하고 코팅횟수가 증가할수록 코팅층의 두께가 두꺼워짐을 확인하였고, 접촉각 측정의 경우 코팅의 농도가 증가하고 코팅횟수가 증가할수록 접촉각이 낮아짐을 확인하였다. 기체 투과 실험 결과 코팅농도가 증가하고 코팅횟수가 증가할수록 산소 기체투과량이 감소하였으며 친수성이 높은 PEBAX 1657로 코팅한 중공사의 기체투과량이 PEBAX 2533과 3533으로 코팅된 중공사보다 낮은 기체투과량을 가짐을 확인하였다.

In this study, hydrophilic coating characteristics of PVDF [poly(vinylidene fluoride)] hollow fiber membranes with flower type cross-section prepared by thermally induced phase separation were studied. The hollow fiber used in this study was provided from PureEnvitech Co. Ltd., and the hydrophilic coating experiment was performed with different concentration and number of coating of PEBAX 1657, 2533 and 3533 block copolymer solution using a dip coating method. The hydrophilic coated hollow fiber membrane was characterized to scanning microscope and contact angle measurements to determine the degree of hydrophilization. As a result of SEM characterization, it was confirmed that the thickness of the coating layer increased as the coating concentration increased and the number of coatings increased. Contact angle of surface of hollow fibers decreased as the concentration of the coating solution increased and the number of coatings increased. Gas permeance of oxygen gas was measured for the application of the hydrophilized hollow fiber to Membrane Areated Biofilm Reactor. As a result of gas permeation test, it was confirmed that gas permeance decreased with increasing coating concentration and number of coatings, and the more hydrophilized hollow fiber coated with PEBAX 1657 showed lower gas permeance than those coated with PEBAX 2533 and 3533.

요 약
Abstract
1. 서 론
2. 실 험
    2.1. 재 료
    2.2. 분리막 코팅용액 준비
    2.3. 분리막 코팅
    2.4. 분리막 기체투과 특성평가
3. 결과 및 고찰
    3.1. 코팅 조건에 따른 코팅층의 변화
    3.2. 코팅에 따른 중공사 표면의 친수화
    3.3. 분리막 기체투과 특성평가
4. 결 론
Reference

• 임광섭(경상대학교 나노신소재융합공학과) | Kwang Seop Im (Department of Materials Engineering and Convergence Technology, Engineering Research Institute, Gyeongsang National University)
• 이정우(경상대학교 나노신소재융합공학과/(주)퓨어엔비텍) | Jeong Woo Lee (Department of Materials Engineering and Convergence Technology, Engineering Research Institute, Gyeongsang National University/Pure Envirech Co. Ltd.)
• 장재영((주)퓨어엔비텍) | Jae Young Jang (Pure Envirech Co. Ltd.)
• 남상용(경상대학교 나노신소재융합공학과) | Sang Yong Nam (Department of Materials Engineering and Convergence Technology, Engineering Research Institute, Gyeongsang National University) Corresponding author
