pp.33-40
PURPOSES : In this study, we examined the installation and the effect of the s-type approach lane marking near the stop line of a typical intersection access road. We examined the possibility of installation and standardization of this facility and its impact on vehicular speed management and carbon emission reduction.
METHODS : To review the installation and standardization possibilities, the geometric size of the marking was set. The possibility of standardization was examined by applying it to lane markings. The velocity before and after the installation of the marking was compared and analyzed through the velocity estimation equation to assess the impact on speed management. Carbon emissions were estimated by comparing the emissions before and after applying the marking.
RESULTS : The s-type approach lane marking can be installed near the stop line of the intersection access road. It was possible to standardize the lane marking by suggesting a formula to determine the size of the geometry. Additionally, the marking enabled vehicular speed management and improvement in the carbon yield. The marking decreased speeds by approximately 10 km/h, from the original speed of 36 km/h to 25.5 km/h after installation. The standard deviation per vehicle was reduced by approximately 5.9 km/h, from 5.8 km/h to 0.9 km/h. Additionally, carbon emissions decreased by 17%, from 14.1 g/40 m to 11.7 g/40 m.
CONCLUSIONS : The geometry and size of the lane marking installation can be set near the stop line of the approach road. Standardization of this facility was also possible. The s-type lane marking, installed at the stop line of the approach road, has the potential to control the speed, reduce the acceleration or deceleration, and reduce the carbon emission. In the future, it is expected that such lane markings can be applied to multi-faceted areas
1. 서론
1.1. 연구목적 및 배경
1.2. 연구의 범위 및 방법
2. 이론적 고찰
2.1. 속도와 기하구조의 관계 추정
2.2. 시케인형 교차로 접근로부에서 속도감소 사례
2.3. 속도 및 가감속에 의한 탄소가스의 발생량
3. 교차로 접근부 마킹의 개발
3.1. 접근부 차선 마킹 도안을 위한 원리식
3.2. 본 연구에서 차선마킹 도안을 위한 적용식
3.3. 본 연구에서 접근로 마킹의 표준
4. 속도의 특성 및 자료수집
4.1. 장소 특성
4.2. 기존의 속도 특성
4.3. 개선 시 속도 특성
5. 개선효과
5.1. 속도와 속도의 일관성 개선효과
5.2. 탄소가스 발생의 개선효과
6. 결론
REFERENCES
