In this research, we have developed the non-contact automatic washer system for two-wheel motor vehicle through structural and fluid analysis. The structural analysis of mainframe was performed for the safety of the bike washer system, and multi-phase fluid analysis was applied for the washer cleaning performance which was analyzed the surface shear stress while varying the nozzle angle. As a result, we have developed the washer system by deriving the spray angle for the shear stress area and by analyzing the housing shape that takes into consideration structural stability. The performance of this washer system was verified by measuring the gloss before and after cleaning in the evaluation of the cleaning performance test of the system.

• 신재호(School of Mechanical and Automotive Engineering, Kyungil University) | Jaeho Shin
• 김희성(R & D Center) | Hee-Sung Kim
• 장용재(청주대학교) | Jang Yong Jae
• 임동균(청주대학교) | IM DONGKYUN Corresponding Author
