Cu2ZnSn(S,Se)4 (CZTSSe) based thin-film solar cells have attracted growing attention because of their earthabundant and non-toxic elements. However, because of their large open-circuit voltage (Voc)-deficit, CZTSSe solar cells exhibit poor device performance compared to well-established Cu(In,Ga)(S,Se)2 (CIGS) and CdTe based solar cells. One of the main causes of this large Voc-deficit is poor absorber properties for example, high band tailing properties, defects, secondary phases, carrier recombination, etc. In particular, the fabrication of absorbers using physical methods results in poor surface morphology, such as pin-holes and voids. To overcome this problem and form large and homogeneous CZTSSe grains, CZTSSe based absorber layers are prepared by a sputtering technique with different RTA conditions. The temperature is varied from 510 oC to 540 oC during the rapid thermal annealing (RTA) process. Further, CZTSSe thin films are examined with X-ray diffraction, X-ray fluorescence, Raman spectroscopy, IPCE, Energy dispersive spectroscopy and Scanning electron microscopy techniques. The present work shows that Cu-based secondary phase formation can be suppressed in the CZTSSe absorber layer at an optimum RTA condition.

Abstract
1.서 론
2. 실험방법
    2.1. 흡수층 제작
    2.2. 태양전지 제작
    2.3. 특성 평가
3. 결과 및 고찰
4.결 론
References

• 김동명(전남대학교 신소재공학과/광전자융합기술연구소) | Dong Myeong Kim (Department of Materials Science and Engineering, Chonnam National University)
• 장준성(전남대학교 신소재공학과/광전자융합기술연구소) | Jun Sung Jang (Department of Materials Science and Engineering, Chonnam National University)
• 비제이 가라데(전남대학교 신소재공학과/광전자융합기술연구소) | Vijay Chandrakant Karade (Department of Materials Science and Engineering, Chonnam National University)
• 김진혁(전남대학교 신소재공학과/광전자융합기술연구소) | Jin Hyeok Kim (Department of Materials Science and Engineering, Chonnam National University) Corresponding author
