군용레이더 전원공급장치의 p-Channel MOSFET 돌입전류 제한 회로 개선에 관한 연구

정성빈; 윤재복

논문 상세보기

군용레이더 전원공급장치의 p-Channel MOSFET 돌입전류 제한 회로 개선에 관한 연구 KCI 등재

A Study on the Improving p-Channel MOSFET Inrush Current Limiter Circuit for the Power Supply Unit of Military Radar

정성빈, 윤재복

언어KOR
URLhttps://db.koreascholar.com/Article/Detail/427142

구독 기관 인증 시 무료 이용이 가능합니다. 4,000원

한국기계기술학회지 (Journal of the Korean Society of Mechanical Technology)

제25권 제5호 (2023.10)
pp.904-910

한국기계기술학회 (Korean Society of Mechanical Technology)

초록

Despite the presence of the p-Channel MOSFET inrush current limiter circuit within the power supply unit of military radar, The internal MOSFET and DC-DC Converter has been damaged due to the high inrush current. In this paper, the cause of the high inrush current was identified by analyzing the p-Channel MOSFET inrush current limiter circuit. Based on the analysis, the high inrush current was reduced by about 60% by adjusting the time constant of the source-to-gate elements compared to before improvement.

키워드

MOSFET(금속 산화물 반도체 전계 효과 트랜지스터)Inrush current limiter(돌입전류 제한기)Inrush current(돌입전류)Time constant(시정수)

저자

정성빈(국방기술품질원) | Sung-Bin Jung (Defence Agency for Technology and Quality) Corresponding author
윤재복(국방기술품질원) | Jae-Bok Yoon (Defence Agency for Technology and Quality)
