Steel plate shear walls (SPSWs) have been recognized as an effective seismic-force resisting systems due to their excellent strength and stiffness characteristics. The infill steel plate in a SPSW is constrained by a boundary frame consisting of vertical and horizontal structural members. The main purpose of this study was to investigate deformation modes and hysteretic characteristics of steel plate shear walls (SPSWs) to consider the effects of their aspect ratios and width-to-thicness ratios. The finite element model (FEM) was establish in order to simulate cyclic responses of SPSWs which have the two-side clamped boundary condition and made of conventional steel grade. The stress distribution obtained from the FEA results demonstrated that the principal stresses on steel plate with large thickness-to-width ratio were more uniformly distributed along its horizontal cross section due to the formation of multiple struts.

1. 서론
2. 강판전단벽의 횡력저항 매커니즘
3. 강판전단벽의 이력특성 분석을 위한해석모델
    3.1 유한요소해석모델 작성
    3.2 유한요소해석모델 검증
4. 강판 형상 및 판폭두께비에 따른 강판전단벽의 변형모드 및 이력특성
    4.1 이력특성 분석
    4.2 변형모드 분석
5. 결론
References

• 신동현(부산대학교 건설융합학부 조교수, 공학박사) | Shin, Dong-Hyeon (School of Urban, Architecture and Civil Engineering, Pusan National University) Corresponding author
