pp.47-55
The aim of this study is to evaluate the possibility of damage to cultural assets resulting from vibrations generated by construction vehicle traffic. The cultural heritage's natural vibration frequency was determined to be 150Hz by measurement. The damping ratios were calculated as 4.7% using the logarithmic decrement approach and 4.3% using the half-power method. The vibration measurements obtained during vehicle operation indicated that, despite an increase in vehicle velocity of up to 15 km/h, the vibrations remained below the detectable level of 0.13 mm/sec. When the road is curved and the terrain is sloped, a suitable speed for vehicle operation was found to be around 17 km/h, at which point vibrations were seen. The highest recorded vibration amplitude at this velocity was 0.217 mm/sec, which remains below the stringent regulation limit of 2 mm/sec. Thus, it can be concluded that there is no actual harm caused by vibrations.
2. 지반 지형 현황
3. 진동 측정 및 분석방법
3.1 측정 장비
3.2 측정 방법
4. 진동 측정 결과 및 분석
4.1 고유진동수 진동측정 결과
4.2 차량 운행시 진동측정 결과
4.3 진동측정 결과 분석
5. 컴퓨터 모델링 및 구조해석
5.1 개요
5.2 재료적 물성치
5.3 해석 결과
6. 결론
References
