공공하수 처리시설 방류수 T-N 기준을 만족하기 위해서는 호기조에서 질산화가 안정적으로 이루어져야 한다. 수온 및 pH가 질산화에 민감한 영향을 주고 있음에도 불구하고 기존 하수처리장 설계 시 동절기 저수온만 고려하고 호기조 pH는 상시 7.0으로 가정하여 설계하고 있다. 이에 본 연구에서는 MLE 공법 하수처리장의 생물반응조 유입수 알칼리도를 계절별로 파악하여 시뮬레이션을 수행하고, 알칼리도 변화가 호기조 pH 및 NH3-N 농도에 주는 영향을 확인하였다. 연구대상 처리장의 계절별 일평균 생물반응조 유입수 알칼리도는 춘/추절기 190 mg CaCO3/L, 하절기 185 mg CaCO3/L 그리고 동절기 210 mg CaCO3/L로 하절기에 저농도 알칼리도가 유입되는 것을 실험을 통해 파악하였다. 시뮬레이션 결과, 동절기 MLSS 농도가 2,500 mg/L인 경우, 유입수 알칼리도 변화와 관계없이 호기조 NH3-N 농도는 10 mg/L 이상이며 알칼리제 투입을 통한 목표 호기조 NH3-N 농도 2.5 mg/L 달성이 어려운 것으로 확인되었다. MLSS 농도가 3,000 및 3,500 mg/L인 경우에는 유입수 알칼리도에 따라 호기조 NH3-N 농도는 각각 1.3-5.0 mg/L와 0.8-3.1 mg/L의 범위인 것을 파악하였다. 춘/추절기 및 하절기 생물반응조 유입수 알칼리도가 하한치가 유입되는 경우, MLSS 및 DO 농도와 관계 없이 pH와 알칼리도가 제한 인자로 작용하여 호기조 NH3-N 농도 2.5 mg/L 이하를 만족하지 못하였다. 반면 유입수 알칼리도가 충분한 조건에서는 DO 및 MLSS 농도만 제어해도 안정적인 질산화가 가능한 것으로 나타났다. 또한 춘/추절기 및 하절기에 호기조 DO 농도가 1.0 mg/L가 되어도 질산화가 발생되는 것이 확인되어 처리장 운영에 있어서 탄소 발생 저감 방안이 수행될 수 있다.
In order to meet the T-N effluent standard at wastewater treatment plants(WWTPs), it is important to maintain stable nitrification in the aerobic tank. Although temperature and pH are known to have a significant impact on nitrification, typical design for nitrogen removal in WWTP only considers winter temperature and assumes a constant pH of 7.0 at aeration tank. In this study, the seasonal variations in influent alkalinity to an MLE process WWTP was defined by experimental measurements, and simulations were performed to determine how changes in alkalinity affected the pH and NH3-N concentration at aerobic tank. The experimental data showed that the average daily influent alkalinity was 190 mg CaCO3/L in spring/fall, 185 mg CaCO3/L in summer, and 210 mg CaCO3/L in winter, respectively, which indicating summer season had the lowest alkalinity. Simulation findings revealed that when the MLSS(Mixed Liquor Suspended Solids) concentration in winter was 2,500 mg/L, the aeration tank NH3-N concentration exceeded 10 mg/L regardless of influent alkalinity, making it difficult to achieve the target NH3-N concentration which is 2.5 mg/L, even with alkaline chemical addition. However, at MLSS levels of 3,000 and 3,500 mg/L, aeration tank NH3-N concentrations had ranges from 1.3 to 5.0 ㎎/L and from 0.8 to 3.1 mg/L, respectively, depending on the influent alkalinity. In the cases the lower limit of alkalinity in spring/fall and summer seasons, pH and alkalinity were emerged as the limiting factors, preventing the aeration tank NH3-N concentration from reaching below 2.5 mg/L, regardless of MLSS and DO(Dissolved Oxygen) concentrations. In contrast, when influent alkalinity was sufficient, stable nitrification was achieved by controlling DO and MLSS concentrations in aeration tank. Also, it is found that nitrification can be occurred at DO concentration 1.0 mg/L in aeration tank during Spring/Fall and this leads lower carbon emission from WWTP.
