슬래브 두께가 다른 비기준층을 포함한 다층지지 RC 구조에서 평균 양생 온도 변화에 따른 슬래브 시공 하중 산정 KCI 등재

Estimation of Slab Construction Loads according to Changes in Average Curing Temperature in Multistory-shored RC Structure including Non-typical Stories with Different Slab Thickness

  • 언어KOR
  • URLhttps://db.koreascholar.com/Article/Detail/443504
모든 회원에게 무료로 제공됩니다.
한국전산구조공학회 논문집 (Journal of the Computational Structural Engineering Institute of Korea)
한국전산구조공학회 (Computational Structural Engineering Institute of Korea)
초록

최근 콘크리트 타설 중 구조체, 거푸집 및 동바리 사고가 지속적으로 발생하고 있으며, 특히 슬래브 두께가 증가한 비기준층이 존 재하는 다층지지 RC 구조 시스템에서 빈번하게 발생하였다. 양생 온도는 콘크리트의 강도와 강성을 결정하는 주요한 요인이며 이에 따라 시공 하중의 분포가 변화한다. 이 연구에서는 양생 온도에 따른 시공 하중의 분포를 분석하기 위하여 온도와 재령에 따른 적산 온도 이론을 사용하여 등가 재령을 계산하고, 이에 따른 슬래브 콘크리트의 강도 및 강성을 산정하여 시공 하중, 시공 손상 변수의 변 화에 대하여 분석하였다. 시공 하중은 평균 양생 온도가 낮아질 때 초기 재령에서는 소폭 감소하고, 충분한 재령이 지난 후에는 증가 하였다. 시공 손상 변수는 평균 양생 온도가 낮아질 때 크게 증가함을 확인하였다.

Recently, accidents involving structural elements, formwork, and shoring during concrete pouring have been occurring with increasing frequency, particularly in multistory-shored RC structural systems with non-typical floors featuring increased slab thickness. Curing temperature is a major factor that determines the strength and stiffness of concrete, thereby affecting the distribution of construction loads. In this study, to analyze the distribution of construction loads as influenced by curing temperature, the equivalent age was calculated using the theory of maturity based on temperature and age. The strength and stiffness of slab concrete were subsequently estimated, and the variations in construction loads and damage parameters during construction were analyzed. The results indicated that construction loads decreased slightly at an early age when the average curing temperature was lower, but increased after sufficient curing time had elapsed. The construction damage parameters exhibited significant increases when the average curing temperature was lower.

목차
Abstract
1. 서 론
2. 슬래브 시공 하중 산정
    2.1 적산온도 산정
    2.2 슬래브 콘크리트 재령에 따른 시공 하중 산정
3. 시공 하중 분석
4. 시공 손상 변수 분석
5. 결 론
감사의 글
요 지
저자
  • 한상민(광운대학교 건축공학과 석사과정) | Sang-Min Han (Graduate Student, Dept. of Architectural Engineering, Kwangwoon University, Seoul, 01890, Korea)
  • 김재요(광운대학교 건축공학과 교수) | Jae-Yo Kim (Professor, Dept. of Architectural Engineering, Kwangwoon University, Seoul, 01890, Korea) Corresponding author
