When manufacturing die casting mold, generally, the casting layout design should be considered based on the relation among injection system, casting condition, gate system, and cooling system. Also, the extent or the location of product defects was differentiated according to the various relations of the above conditions. In this research, in order to optimize casting design of an automobile part (Gear Box) Computer Aided Engineering (CAE) was performed by using the simulation software (ZَCast). The simulation results were analyzed and compared with experimental results. During the mold filling, internal porosities caused by air entrap were predicted and reduced remarkably by the modification of the gate system and the configuration of overflow. With the solidification analysis, internal porosities caused by the solidification shrinkage were predicted and reduced by the modification of the gate system. For making a better production dieَcasting tool, cooling systems on several thick areas are proposed in order to reduce internal porosities caused by the solidification shrinkage.

• 권홍규(남서울대학교 산업경영공학과) | Hongkyu Kwon
• 장무경(남서울대학교 산업경영공학과) | Moo-Kyung Jangٜ Corresponding Author
