pp.1-9
The coaxial sample holder with 20mm in diameter and the adaptor from type N connector-to-20mmΦ coaxial tube are designed and manufactured which have been used for designing and measuring the fabricated microwave absorber. In addition, the measure in method of material constants of the microwave absorbers is described, which is focused on minimizing the error due to the sample's shapes, the fitting conditions, etc. After describing the design method of a single-layed microwave absorber, the microwave absorbers for X-band, C-band and S-band RADARs are designed and fabricated, respectively, which are composed of ferrite, carborn, and binder and have good performance. Futhermore, we develop the high performance microwave absorber in extremely wide-band type for RADAR, which is composed of different material and its mixing ratio and which could cover nearly from 4 to 10 GHz.
