The honeycomb aluminum foam of the porous metal has the merit of the impact absorption, the soundproof, the heat conductivity, the light weight. Aluminum 6061-T6 is used at the materials for the automobile, the ship, the machine and various structures. In this study, the sandwich combined with the honeycomb aluminum foam and aluminum 6061-T6 is simulated with the impact. Two kinds of models made by use of CATIA program with 3 kinds of impact energies are analyzed by ANSYS program. As the simulation result, the maximum deformations at the cases of 1 and 2 are shown as 4.8205mm and 11.909mm respectively. And the maximum equivalent stresses at the cases of 1 and 2 are shown as 274.45MPa and 265.6MPa respectively. As the simulation result at case 1 approaches the experimental result, all simulation results can be verified in order to apply into analyzing the impact properties of the honeycomb aluminum foam sandwiches. In cases of three kinds of impact energies, the striker is not shown to penetrate the upper face sheets of case 1. At the impact energy of 100 J, the striker is not shown to penetrate the upper face sheets of case 2. At the impact energies of 200 J and 300 J, the striker is shown to penetrate the upper face sheets of case 2. It is thought to predict and improve the structural safety the composite material combined with the aluminium foam by using this study result.

1. 서 론
 2. 해석방법 및 결과
  2.1 해석모델
  2.2 해석조건
  2.3 해석결과
 3. 해석 결과와 실험에 의한 검증 및 고찰
 4. 결 론
 후 기
 참 고 문 헌

• 고등(공주대학교 기계공학과 대학원) | Teng Gao
• 조재웅(공주대학교 기계자동차공학부) | Jae-Ung Cho Corresponding Author
